From Newsgroup: alt.os.linux.mint
On Thu, 2/12/2026 7:32 AM, Alan K. wrote:
I would bet money you know this but, even efibootmgr won't allow you to remove those boot names on that one problematic PC?-a-a Or is the issue
more that what that command fixes?
OK, first let us review the objective.
The objective is to get PCA 2023 to install (which is needed by *both* Windows and Linux,
as the Linux shim will switch over to signing via PCA 2023 as well). The Microsoft software
thinks it is installing a certificate, to replace an expiring one (PCA 2011 or so). A lot
of existing Linux shims are signed with PCA2011). While the plan is to install PCA2023
and remove PCA2011, I'm not in a rush to remove the old one (even though that may
compromise security).
Now, I would not care, that Ubuntu has injected something of its own.
Except the Big Machine I am using as a Secure Boot Test Donkey, is now
*stuck* and with the paucity of tools, I don't really know why.
I can see two what might be Canonical certificates, with similar sounding names,
implying these *might* have something to do with the certificate structure. By backing up the four files (to be described below) and by using a hex editor, I can see materials which are not present on another AMD machine with four files.
On the Big Machine in question, the Microsoft software is unable to install
the PCA 2023 materials. I believe I have tried a recipe, where you back up the PK,
delete the PK, which "relaxes" Secure Boot, boot into Windows, try to do the update,
nothing good happens, put the PK file back, the conditions previously present are
back again.
Two things are possible. The BIOS is brain dead. It's an Asus motherboard.
But even when Recovery Mode was used (which takes the permissions *off*
that stuff), the Microsoft software is *still* unable to make headway.
If I use E18592 ROG STRIX B550F GAMING WI-FI II manual, the manual described the
area I am working, this way:
******* Copied BIOS Manual content (a BIOS common to a set of similar Asus AMD motherboards) *******
Key Management
Clear Secure Boot keys
This item appears only when you load the default Secure Boot keys.
This item allows you to clear all default Secure Boot keys.
Save all Secure Boot variables <=== on my USB stick somewhere
This item allows you to save all the Secure Boot keys to a USB storage device.
PK Management
The Platform Key (PK) locks and secures the firmware from any permissible changes.
The system verifies the PK before your system enters the OS.
Save to file
Set New key (downloaded PK from a USB storage device)
Delete key (delete the PK from your system -- the system's Secure Boot keys will not be active)
KEK Management
The Key Exchange Keys (KEK) manages the Signature database (db) and Forbidden Signature database (dbx).
Key Exchange Keys (KEK) refers to Microsoft Secure Boot Key-Enrollment Key (KEK).
Save to file
Set New key (downloaded KEK from a USB storage device)
Append Key (load the additional KEK from a storage device for additional db and dbx management)
Delete key
The KEK file must be formatted as a UEFI variable structure with time-based authenticated variable.
DB Management
The Authorized Signatures (db) lists the signers or images of UEFI applications,
operating system loaders, and UEFI drivers that you can load on the single computer.
Save to file
Set New key (downloaded db from a USB storage device)
Append Key (load the additional db from a storage device for an additional db and dbx loaded management)
Delete key (allows you to delete the db file from your system)
The db file must be formatted as a UEFI variable structure with time-based authenticated variable.
DBX Management
The Forbidden Signature database (dbx) lists the forbidden images of db items
that are no longer trusted and cannot be loaded.
Save to file (save the dbx to a USB storage device)
Set New key (downloaded dbx from a USB storage device)
Append Key (load the additional dbx from a storage device for an additional db and dbx loaded management)
Delete key (allows you to delete the dbx file from your system)
The dbx file must be formatted as a UEFI variable structure with time-based authenticated variable.
******* End BIOS Manual content Asus AMD motherboard *******
Without the tools (so I can stop using a Hex Editor), it's pretty hard
to figure out what is what in there. I need a tool that can parse the
four files, and print out text titles for them. So I can see what
the Canonical ones claim to be.
My mistake (and others can benefit from this), is NOT backing up these four files of keys at BIOS level, when the board was new. I had NO IDEA you could back up the keys to a USB stick, at BIOS level. The backup I have, merely allows me to experiment and trash the key storage, then put it back... in
its broken state. Flashing a BIOS doesn't do anything for you (I upgraded
the BIOS to no effect). And it's just as likely any "Clear" function, will leave dick in there, and then I'm really screwed. Absolutely none of the documentation has a stance of "understanding what it documents".
*******
THIS is what owners of year 2026 computers are facing. They will be given PCs with
Secure Boot enabled, no disable, all the OSes installed will install in
Secure Boot mode, one dick of an OS will fuck around in the key store,
the key store will be ruined, the offending company will pretend it
doesn't know what it's doing and... well, write yourself a sad story.
I don't think flashing the BIOS, re-populates the key store, which is in
the NVRAM area with the boot paths. There may be some NVRAM management somewhere,
but I haven't run into it. 4MB is typically set aside for boot paths -- sometimes
the BIOS seems to "consolidate" some of the materials (the popup boot menu
may be "different" from one boot to the next). The NVRAM is an area of the NOR flash
chip, rather than being some part of the 256 byte CMOS RAM (CR2032 powered).
Success criterion:
All test OSes (Linux on SSD#11 and Windows on another SSD) boot without
the UEFI messages indicating anything is broken. You must record the
screen with a video camera, to capture the necessary success messages.
The Break key does not stop the screen during UEFI "ceremonies" like it
would have on a Legacy BIOS.
Paul
